Dimensions
Height: 35.375”
(899 mm)
Width: 22”
(559 mm)
Depth: 30.5”
(775 mm)
Space Required
24” W x 31.5” D
(610 mm W x 800 mm D)
Electrical
115V/60Hz, 3Amps
230V/50Hz, 1.5Amps
Weight
With ice: 405 lbs
(184 kg)
Shipping: 255 lbs
(116 kg)
Ice
Capacity: 180 lbs
(82 kg)
Dispensable: 150 lbs
(68 kg)
Fittings
Soda Inlets: 3/8”
(9.5 mm) male barb
Syrup Inlets: 3/8”
(9.5 mm) male barb
Dimensions
Height: 35.375”
(899 mm)
Width: 25”
(635 mm)
Depth: 30.5”
(775 mm)
Space Required
27” W x 31.5” D
(686 mm W x 800 mm D)
Electrical
115V/60Hz, 3Amps
230V/50Hz, 1.5Amps
Weight
With ice: 460 lbs
(208 kg)
Shipping: 290 lbs
(132 kg)
Ice
Capacity: 205 lbs
(93 kg)
Dispensable: 160 lbs
(73 kg)
Fittings
Soda Inlets: 3/8”
(9.5 mm) male barb
Syrup Inlets: 3/8”
(9.5 mm) male barb
Dimensions
Height: 35.375”
(899 mm)
Width: 30”
(762 mm)
Depth: 30.5”
(775 mm)
Space Required
32” W x 31.5” D
(813 mm W x 800 mm D)
Electrical
115V/60Hz – 230/50Hz
Weight
With ice: 525 lbs
(238 kg)
Shipping: 305 lbs
(138 kg)
Ice
Capacity: 250 lbs
(113 kg)
Dispensable: 175 lbs
(79 kg)
Fittings
Soda Inlets: 3/8”
(9.5 mm) male barb
Syrup Inlets: 3/8”
(9.5 mm) male barb
Dimensions
Height: 35.375”
(899 mm)
Width: 44”
(1118 mm)
Depth: 30.5”
(775 mm)
Space Required
46” W x 31.5” D
(1168 mm W x 800 mm D)
Electrical
115V/60Hz – 230/50Hz
Weight
With ice: 760 lbs
(345 kg)
Shipping: 460 lbs
(209 kg)
Ice
Capacity: 360 lbs
(163 kg)
Dispensable: 300 lbs
(136 kg)
Fittings
Soda Inlets: 3/8”
(9.5 mm) male barb
Syrup Inlets: 3/8”
(9.5 mm) male barb
