Dimensions
Height: 26.9” (683 mm)
Width: 9.2” (234 mm)
Depth: 17.1” (434 mm)

Weight
Shipping: 40 lbs (18.14 kg)
Operating: 35 lbs (15.88 kg)

Electrical
24 VDC / 2.0 Amps

Flow Rate
1.5 – 2.0 ounces per second

Carbon Dioxide (CO2) Supply
Min Pressure: 70 psi (0.483 MPa)
Max Pressure: 80 psi (0.552 MPa)

Fittings
Carb Water Inlet: 3/8 inch (9.5 mm) barb
Carb Water Outlet: 3/8 inch (9.5 mm) barb
Plain Water Inlet: 3/8 inch (9.5 mm) barb
Brand Syrup Inlets: 3/8 inch (9.5 mm) barb
Drain Fitting: 5/8 inch (15.9 mm) barb
