Dimensions
Height: 40.6”
(1031.2 mm)
Width: 30”
(762 mm)
Depth: 34.25”
(869.9 mm)

Space Required
Width: 32”
(1168.4 mm)
Depth: 36”
(1016 mm)
Height:

Electrical
115V/60Hz, 5 Amps
220-240V, 50/60 Hz, 2.5 Amps

Weight
With Ice: 570 lbs
(258.5 kg)
Shipping: 290 lbs
(131.5 kg)

Ice
270 lbs
(122.5 kg)
Accepts 30” &  22” W Ice Makers
(adapters may be required)

Fittings
Soda Inlets: 3/8”
(9.5mm) male barb
Syrup Inlets: 3/8”
(9.5mm) male barb

Flex Manifold Configuration
Total carb / non carb flexibility
Up to 24 brands
(16 chilled / 8 ambient)
