Dimensions
Height: 39.375” (1000.1 mm)
Width: 44” (1117.6 mm)
Depth: 31” (787.4 mm)

Space Required
Width: 46” (1168.4 mm)
Depth: 40” (1016 mm)
Height: Refer to ice maker
recommendation for top
clearance.

Electrical
115V/60Hz, 6 Amps
220-240V, 50/60 Hz, 3 Amps

Weight
With Ice: 745 lbs (337.9 kg)
Shipping: 585 lbs (265 kg)

Ice
Capacity: 312 lbs (142 kg)
Dispensable: 255 lbs (116 kg)
Accepts 30” and 22” and 44” wide ice makers
(adapters may be required)

Fittings
Soda Inlets: 3/8” (9.5mm) male barb
Syrup Inlets: 3/8” (9.5mm) male barb

Flex Manifold Configuration
Total carb / non carb flexibility
Up to 24 brands
(10 chilled / 2 ambient per nozzle)
Up to 8 bonus Flavors (4 per nozzle)
