Dimensions
Height: 40.25”
(1022 mm)
Width: 22”
(558 mm)
Depth: 30.5”
(775 mm)
Electrical
115V / 60Hz, 7Amps
230V / 50Hz, 3.5Amps
Weight
Without Ice: 280 lbs
(127 kg)
With Ice: 480 lbs
(218 kg)
Shipping: 310 lbs
(141 kg)
Ice
Capacity: 200 lbs
(91 kg)
Dispensable: 170 lbs
(77 kg)
Fittings
Syrup inlets: 3/8”
(9.5 mm) male barb
Soda inlets: 3/8”
(9.5 mm) male barb
Water
Filtered water 50 psi min
(Water booster recommended)
Dimensions
Height: 40.25”
(1022 mm)
Width: 30”
(762 mm)
Depth: 30.5”
(775 mm)
Electrical
115V / 60Hz, 7Amps
Weight
Without Ice: 320 lbs
(145 kg)
With Ice: 610 lbs
(281 kg)
Shipping: 356 lbs
(161 kg)
Ice
Capacity: 280 lbs
(127 kg)
Dispensable: 215 lbs
(98 kg)
Fittings
Syrup inlets: 3/8”
(9.5 mm) male barb
Soda inlets: 3/8”
(9.5 mm) male barb
Water
Filtered water 50 psi min
(Water booster recommended)
Dimensions
Height: 40.25”
(1022 mm)
Width: 44.875”
(1140 mm)
Depth: 30.5”
(775 mm)
Electrical
115V / 60Hz, 7Amps (2x)
Weight
Without Ice: 620 lbs
(282 kg)
With Ice: 1020 lbs
(464 kg)
Shipping: 710 lbs
(323 kg)
Ice
Capacity: 400 lbs
(181 kg)
Dispensable: 340 lbs
(154 kg)
2 Independent Ice Bins
Fittings
Syrup inlets:
3/8” (9.5 mm) male barb
Soda inlets:
3/8” (9.5 mm) male barb
Water
Filtered water 50 psi min
(Water booster recommended)
Dimensions
Height: 40.25”
(1022 mm)
Width: 60.75”
(1543 mm)
Depth: 30.5”
(775 mm)
Electrical
115V / 60Hz, 7Amps (2x)
Weight
Without Ice: 640 lbs
(290 kg)
With Ice: 1100 lbs
(500 kg)
Shipping: 712 lbs
(322 kg)
Ice
Capacity: 580 lbs
(264 kg)
Dispensable: 430 lbs
(195 kg)
2 Independent Ice Bins
Fittings
Syrup inlets: 3/8”
(9.5 mm) male barb
Soda inlets: 3/8”
(9.5 mm) male barb
Water
Filtered water 50 psi min
Water booster recommended
