Dimensions
Height: 40.6” (1031.2 mm)
Width: 30” (762 mm)
Depth: 31” (787mm)

Space Required
Width: 32” (1168.4 mm)
Depth: 36” (1016 mm)

Electrical
115V/60Hz, 5 Amps

Weight
With Ice: 570 lbs (259 kg)
Shipping: 290 lbs (132 kg)

Ice
270 lbs (173 kg)
Accepts 30” & 22” wide
Ice Makers
(adapters may be required)

Fittings
Soda Inlets: 3/8”
(9.5mm) male barb
Syrup Inlets: 3/8”
(9.5mm) male barb

Flex Manifold Configuration
Total carb / non carb flexibility
Up to 24 brands
(16 chilled / 8 ambient)
