Dimensions
Height: 39””
(1000 mm)
Width: 44”
(1118 mm)
Depth: 31”
(797 mm)
Electrical
115V/60Hz, 6 Amps
220V/50Hz, 3 Amps
220V/60Hz, 3 Amps
Weight
Empty: 146 lbs
(66.2 kg)
Operating: 193 lbs
(87.5 kg)
Shipping: 160 lbs
(72.5 kg)
Ice
Capacity: 312 lbs
(141.5 kg)
Dispensable: 255 lbs
(115.6 kg)
Fittings
Carbonated Water Inlet: 3/8”
(9.5 mm) male flare
Plain Water inlet: 3/8”
(9.5 mm) male barb
Syrup inlets: 1/4”
(6.35 mm) male barb
Dimensions
Height: 30”
(764 mm)
Width: 10.8”
(275 mm)
Depth: 28”
(719 mm)
Electrical
115V/60Hz, 6 Amps
220V/50Hz, 3 Amps
220V/60Hz, 3 Amps
Weight
Empty: 146 lbs
(66.2 kg)
Operating: 193 lbs
(87.5 kg)
Shipping: 160 lbs
(72.5 kg)
Ice
Capacity: 250 lbs
(113 kg)
Dispensable: 185 lbs
(84 kg)
Fittings
Carbonated Water Inlet: 3/8”
(9.5 mm) male flare
Plain Water inlet: 3/8”
(9.5 mm) male barb
Syrup inlets: 1/4”
(6.35 mm) male barb
