Dimensions
Height: 26.86” (682 mm)
Width: 16.86” (428 mm)
Depth: 25.56” (649 mm)
Electrical
115V/60Hz, 8 Amps
230V/50Hz, 4 Amps
Weight
Empty: 160 lbs (73 kg)
Operating: 240 lbs (109 kg)
Shipping: 180 lbs (82 kg)
Ice Bank Weight
20 lbs (9 kg)
Fittings
Carbonated Water Inlet:
3/8”(9.5 mm) male flare
Plain Water inlet:
3/8”(9.5 mm) male barb
Syrup inlets:
1/4”(6.35 mm) male barb
Compressor
407W (230V/50Hz)
285W (115V/60Hz)
Dimensions
Height: 30” (764 mm)
Width: 10.8” (275 mm)
Depth: 28” (719 mm)
Electrical
115V/60Hz, 6 Amps
220V/50Hz, 3 Amps
220V/60Hz, 3 Amps
Weight
Empty: 146 lbs (66.2 kg)
Operating: 193 lbs (87.5 kg)
Shipping: 160 lbs (72.5 kg)
Ice Bank
Capacity: 14 lbs (6.4 kg)
1/3 hp Compressor
285W (115V/60Hz)
450W (220V/50Hz)
400W (220V/60Hz)
Fittings
Carbonated Water Inlet:
3/8”(9.5 mm) male flare
Plain Water inlet:
3/8”(9.5 mm) male barb
Syrup inlets: 1/4”(6.35 mm) male barb
Dimensions
Height: 32.27” (820 mm)
Width: 23.96” (609 mm)
Depth: 28.49” (724 mm)
Electrical
115V/60Hz, 12 Amps
220-240V/50Hz, 7.5 Amps
Weight
Empty: 220 lbs (99.8 kg)
Operating: 370 lbs (168 kg)
Shipping: 158 lbs (72 kg)
Compressor
3/4 hp
Ice
Capacity: 50 lbs (23 kg)
Fittings
Soda Inlets:
3/8” (9.5 mm) male barb
Syrup Inlets:
3/8” (9.5 mm) male barb
Motor
Agitator : 25w
Condenser Fan: 35w
Flex Manifold Configuration
Total Carb / Non-Carb Flexibility
