LEV SSL (4.5)

Lancer Electric Valve The LEV® is the best in class and best selling valve on the market. It is built with the highest quality materials and proven technology to provide our customers with consistent drink quality and reliability.

Read full details

Product Details

description

Lancer Electric Valve
The LEV® is the best in class and best selling valve on the market. It is built with the highest quality materials and proven technology to provide our customers with consistent drink quality and reliability.
LEV® Valves
  • Over six million valves produced since 1987
  • Available in 3 and 4.5 oz/second flow rates
  • Consistent “Best in Class” performance
  • Lowest “Life Cost” of operation available
  • Simple design gives high reliability
  • Widest range of ratio control (2:1 - 10:1)
  • Tamper-proof ratio setting

PRESSURE REQUIREMENTS

  • Water: 40 - 110 psig (2.8 - 7.7 bar)

  • Syrup (Sugar): 20 - 70 psig (1.4 - 4.9 bar)

  • Syrup (Diet/Light): 10 - 70 psig (0.7 - 4.9 bar)

DRINK FLOW RATES

  • LEV 3.0: 1.5 oz/s - 3.0 oz/s (44.4 ml/s – 88.8 ml/s)

  • LEV 4.5: 2.5 oz/s - 4.5 ox/s (73.9 ml/s – 133.1 ml/s)

RATIO ADJUSTMENT RANGE

  • 2.0 - 10.0 Water/Syrup by Volume (dependent on finished drink flow rate)

ELECTRICAL REQUIREMENTS

  • 24V, 50/60 Hz

MOUNTING

  • Uses LEV® Mounting Block

  • LEV® mounting block has the same mounting screw hole pattern as the following:

  • Dole SEV

  • Dole FFV

  • Cornelius UF1, SF1

  • McCann Turbo Flo Jr.

-->
