Height: 40.25” (1022 mm)
Width: 44.88” (1140 mm)
Depth: 30.5” (775 mm)
Height: Allow sufficient clearance for manually filling with ice or refer to ice maker recommendation for top clearance.
Width: 46.88” (1191 mm)
Depth: 31.5” (800.1 mm)
(2) 120V/60Hz, 14AMPs
Without Ice: 620 lbs (282 kg)
With Ice: 1020 lbs (464 kg)
Shipping: 710 lbs (323 kg)
Capacity: 400 lbs (181 kg)
Dispensable: 215 lbs (98 kg)
Soda Inlets: 3/8" (9.5mm) barb
Syrup Inlets: 3/8" (9.5mm) barb
Filtered water 50 psi min required
Lancer Flow Control Valves(LFCV)
