ECO POUR MECHANICAL SSL

ECO-friendly & ECOnomical Green valve, with recyclable parts > A mechanical actuation that requires no electricity and even works under brown or black-out conditions!

Read full details

Product Details

description

ECO-friendly & ECOnomical
  • Green valve, with recyclable parts
  • A mechanical actuation that requires no electricity and even works under brown or black-out conditions!
  • Clever and ultra-reliable design eliminates the two leading causes (solenoid and switch activation) of service calls/failure
  • Lowest life cost valve delivers reliable performance at a sensible price and continued savings from a lack of energy consumption

PRESSURE REQUIREMENTS

  • Water: 40 - 100 psig (2.8 - 6.89 bar)

  • Syrup (Sugar): 40 - 80 psig (2.8 - 5.5 bar)

  • Syrup (Diet/Light): 40 - 80 psig (2.8 - 5.5 bar)

ELECTRICAL REQUIREMENTS

  • N/A

DRINK FLOW RATES

  • 1.5 oz/s (44.4 ml/s)

FLOW WASHER

  • Only has an adjustable syrup flow wash, water flow non-adjustable.

OPERATING TEMPERATURE

  • 32° F (0° C) – 105° F (40.6° C)

STANDARD LANCER MOUNTING BLOCK

  • EcoPour mounting block has the same mounting screw hole pattern as the following:

  • Dole SEV

  • Dole FFV

  • Cornelius UF1, SF1

  • McCann Turbo Flo Jr.
