DELTA 9100 REMOTE REM,9100,115/60,NP,HICAP,NOKIT,GB

Delta 9100 High Performance Remote Recirculation System The Lancer Delta 9100 CED Remote Recirculation system is a benchmark in the fountain dispensing market. Built to the quality standards that Lancer is known for, this compact unit utilizes cold carbonation and a stainless steel recirculating

Read full details

Product Details

description

Delta 9100 High Performance Remote Recirculation System
The Lancer Delta 9100 CED Remote Recirculation system is a benchmark in the fountain dispensing market. Built to the quality standards that Lancer is known for, this compact unit utilizes cold carbonation and a stainless steel recirculating pump to provide optimum temperature product to a remote tower location. It is perfect for use with the Lancer Unicorn dispensing unit, or any tower with up to six valves.
  • Cold carbonation
  • Stainless steel cabinet, tank and product lines
  • CFC free refrigerant
  • Zero GWP structural insulation
  • Lancer Electronic Ice Bank Control (EIBC)
  • Lancer Electronic Liquid Level Control (LLC)

DIMENSIONS

  • Height: (without legs) 25.875” (657 mm)

  • Width: 16.563” (421 mm)

  • Depth: 25.531” (674 mm)

WEIGHT

  • Empty: 156 lbs (70.8kg)

  • Operating: 220 lbs (98.8 kg)

  • Shipping: 170 lbs (77.1 kg)

ELECTRICAL

  • 115V/60hz

  • 230V/50hz

WATER REQUIREMENTS

  • Minimum flowing pressure of 25 PSIG (1.76 kg/cm2, 1.72 BAR)

  • Maximum static pressure of 50 PSIG (3.52 kg/cm2, 3.45 BAR)

ICE BANK WEIGHT

  • 25-28 lbs (11.3kg - 12.7kg)

CARBON DIOXIDE (CO2) REQUIREMENTS

  • Minimum pressure of 70 PSIG (4.92 kg/cm2, 4.83 BAR)

  • Maximum pressure of 80 PSIG (5.62 kg/cm2, 5.52 BAR)
