Ice Beverage Dispenser

IBD 30"

The IBD is Lancer’s #1 selling self-serve dispenser. Hard plumbed syrup and water lines deliver excellent icy cold drinks. Versatile valve configurations and a portion control option allow for easy beverage cost monitoring. Topped with a compelling wraparound display, the IBD is a favorite.

Request A Quote

SPECIFICATIONS

↓

Equipment Warranty

Versatile Valve Options

IBD 30 supports both 8‑valve and 10‑valve configurations, allowing operators to tailor offerings to their beverage portfolio. Portion‑control compatibility helps maintain consistent pours and manage product costs.

Larger Ice Capacity for Busy Locations

With a 250‑lb ice capacity and 175‑lb dispensable volume, the IBD 30 is designed for steady, all‑day beverage demand. Its unique hex‑drive agitation system keeps ice flowing smoothly for trouble‑free dispensing.

Specifications

Dimensions
Width: 30.0 in (762 mm)
Depth: 30.5 in (775 mm)
Height: 34.0 in (864 mm)

Space Required
Width: 32 in (813 mm)
Depth: 31.5 in (800 mm)

Weight
Shipping: 305 lb (139 kg)
Empty (without Ice): 275 lb (125 kg)

Electrical
115 VAC / 60 Hz / 3.6 Amps
230 VAC / 50-60 Hz / 1.8 Amps

Ice
Capacity: 250 lb (113 kg)
Dispensable: 175 lb (79 kg)

Features

› Illuminated interchangeable front graphics

› High capacity ice storage bin

› Stainless steel construction; exterior and interior

› High capacity drip tray helps avoid safety hazards and drink station cleanup from spills

› Unique hex drive ice agitation and dispense drive system

› Multiple valve configurations available for self-serve and portion control operation

› Fully insulated storage bin and drip tray to control condensation and avoid moisture related safety hazards

› Front and rear plumbing access for installation flexibility

› LEV® valves standard, other valves available upon request

› Key lock switch
